PYREX® Replacement Extractor Body for One-Piece Continuous Heavier-than-Water Liquid-Liquid Extractor System

The PYREX® Replacement Extractor Body is a laboratory-grade glass component designed for the 1 L PYREX® One-Piece Continuous Heavier-than-Water Liquid/Liquid Extractor System. It features an integrated elevated sidearm and precision standard taper joints for connection to compatible laboratory condensers and boiling flasks. This replacement body supports continuous liquid-liquid extraction using solvents denser than the sample liquid, making it suitable for environmental analysis, chemical testing and laboratory sample preparation. Key Features - Genuine PYREX® Replacement Component: Designed for Corning laboratory extraction equipment. - 1 L System Compatibility: Specifically designed for the PYREX® 3920-M extractor system. - One-Piece Glass Construction: Integrated extractor body with permanently attached sidearm. - 45/50 Upper Joint: Standard taper connection for the compatible Allihn condenser. - 24/40 Lower Joint: Standard taper connection for the compatible boiling flask. - Elevated Sidearm Design: Helps minimise water overflow when draining residual solvent. - Continuous Extraction: Supports extraction procedures involving solvents heavier than the sample liquid. - Replacement Function: Allows damaged extractor bodies to be replaced separately. - Laboratory Applications: Suitable for environmental testing, analytical chemistry and solvent extraction. Specification Details Brand PYREX® Manufacturer Corning Product Number 3920-MBO Product Type Replacement Extractor Body Compatible Extractor Capacity 1,000 mL (1 L) Material Laboratory-grade PYREX® Glass Construction One-Piece Glass Body Sidearm Integrated Elevated Glass Sidearm Upper Joint Type Standard Taper Upper Joint Size 45/50 Lower Joint Type Standard Taper Lower Joint Size 24/40 Approximate Body Height 355 mm Approximate Body Width 214 mm Compatible System PYREX® 3920-M Compatible Condenser PYREX® 3840-MCO Compatible Boiling Flask PYREX® 4320-500 Extraction Method Continuous Liquid-Liquid Extraction Solvent Application Solvents Denser Than Sample Liquid Quantity per Case 1 Piece Supplied Component Extractor Body Only
