Mindray Reaction Cuvettes Old Type for BS-430

The Mindray Reaction Cuvettes Old Type for BS-430 are semi-permanent plastic reaction vessels designed for the Mindray BS-430 Clinical Chemistry Analyzer. Each cuvette provides a controlled optical reaction chamber in which clinical chemistry reagents and patient samples are dispensed, mixed and incubated before absorbance measurement. The BS-430 reaction carousel accommodates 93 cuvettes, which move through reagent dispensing, sample dispensing, mixing, photometric measurement and automatic washing positions during analyzer operation. Unlike disposable reaction cups, the BS-430 cuvettes are reusable/semi-permanent. After testing, the analyzer automatically washes and dries them for subsequent use. The BS-430 technical documentation specifies an eight-stage automatic cuvette washing process. Key Features Specifically intended for the Mindray BS-430 Old-type BS-430 reaction cuvette configuration Semi-permanent reusable design Precision plastic construction 5 mm optical light path Internal dimensions approximately 5 × 5 × 29 mm Supports reaction volumes of 100–300 µL Works with the BS-430 automatic cuvette washing system Suitable for photometric clinical chemistry reactions Individual cuvettes can be replaced when damaged, scratched or contaminated Designed for routine automated clinical chemistry testing
