Mindray BS-430 Plastic Reaction Cuvettes Old Type

The Mindray BS-430 Plastic Reaction Cuvettes Old Type are reusable optical reaction vessels designed for the reaction and photometric measurement system of compatible Mindray BS-430 Clinical Chemistry Analyzers. Each cuvette holds the sample and reagent mixture during automated clinical chemistry testing. As the BS-430 reaction carousel rotates, cuvettes are moved through reagent dispensing, sample dispensing, mixing, reaction, photometric measurement and washing stages. The BS-430 operator documentation describes the reaction cuvette as a semi-permanent plastic cuvette with an internal dimension of approximately 5 × 5 × 29 mm and an optical path length of 5 mm ±0.03 mm. After testing, the analyzer automatically washes and dries the cuvette for subsequent use. Key Features Designed for the Mindray BS-430 Clinical Chemistry Analyzer Reusable / semi-permanent plastic construction Transparent optical reaction vessel Approximately 5 mm optical path length Supports 100–300 µL BS-430 reaction volumes Used for automated photometric chemistry assays Compatible with the BS-430 reaction carousel BS-430 accommodates 93 reusable cuvettes Compatible with the analyzer's automatic 8-step washing process Individual cuvettes can be replaced when required Suitable as a replacement analyzer consumable “Old Type” designation helps distinguish the required physical version
