Dymind DF55 Mini 5-Part Hematology Analyzer

The Dymind DF55 5-Part Hematology Analyzer is a compact automated blood-cell analyzer designed for routine hematology testing in hospitals, diagnostic centres, clinics and clinical laboratories. For white blood cell differentiation, the DF55 combines flow cytometry (FCM) with tri-angle laser scatter technology. It uses the impedance method for RBC and platelet testing and cyanide-free colorimetry for hemoglobin measurement. The analyzer delivers up to 60 tests per hour while requiring only 20 µL of sample, making it particularly useful for laboratories looking for 5-part differential capability in a relatively compact system. It supports venous whole blood, capillary whole blood and pre-diluted sample modes. Key Features 5-part WBC differential Up to 60 tests per hour Only 20 µL sample volume Flow cytometry + tri-angle laser scatter Impedance measurement for RBC and PLT Cyanide-free colorimetric HGB testing 25 reportable parameters 6 research parameters 3 histograms: WBC, RBC and PLT 3 DIFF scattergrams + 1 BASO scattergram Whole blood, capillary whole blood and pre-diluted modes 10.4-inch TFT touchscreen Stores up to 100,000 records Built-in 57 mm thermal printer Supports external laser/inkjet printers LAN with HL7 protocol Bi-directional LIS support 4 USB ports and 1 LAN port Compact benchtop design
