Agappe Mispa HX35 Advanced 3-Part Differential Hematology Analyzer

The Agappe Mispa HX35 is a compact automated 3-part differential hematology analyzer developed for fast and efficient CBC testing in clinical laboratories, hospitals, diagnostic centres and other healthcare facilities. The analyzer processes up to 72 samples per hour and reports 24 hematology parameters plus three histograms. It requires only 8.5 µL of whole blood, making it suitable for laboratories where low sample-volume requirements and high routine throughput are important. For cell counting, the HX35 uses Agappe's Transducer Impedance Counting (TIC) technology for WBC, RBC and platelet measurements, while hemoglobin is determined using photoelectric colorimetry with a cyanide-free reagent. Its 10.4-inch colour LCD touchscreen, built-in thermal printer, large data-storage capacity, QC functions and LIS/HIS connectivity make it a practical benchtop hematology system for routine laboratory workflow. 3. Key Features Automated 3-part differential hematology analysis 24 parameters + 3 histograms High throughput of 72 samples/hour Only 8.5 µL whole blood required 20 µL pre-diluted blood sampling TIC electrical impedance technology Cyanide-free hemoglobin measurement 10.4-inch colour LCD touchscreen 800 × 600 display resolution Open-vial sampling Up to 1,000,000 results stored with histograms Built-in thermal printer LIS/HIS compatibility using HL7 protocol L-J, X, X-R and X-B QC modes Manual and automatic calibration USB connectivity Barcode reader support Two-reagent system RFID reagent technology Automatic clog-removal function Internal diluent preheating Compact benchtop design Detailed Technical Specifications Specification Agappe Mispa HX35 Analyzer Type Automated Hematology Analyzer Differential 3-Part Parameters 24 Parameters Histograms 3 Throughput 72 Samples/Hour WBC/RBC/PLT Principle TIC / Electrical Impedance HGB Principle Photoelectric Colorimetry HGB Reagent Cyanide-Free Sampling Open Vial Whole Blood Volume 8.5 µL Pre-Diluted Blood Volume 20 µL WBC Aperture 100 µm RBC/PLT Aperture 68 µm Display 10.4-inch Colour LCD Touchscreen Display Resolution 800 × 600 Data Storage Up to 1,000,000 results with histograms QC Modes L-J, X, X-R, X-B Calibration Manual & Automatic LIS/HIS Supported Communication Protocol HL7 Connectivity Mouse, Keyboard, Printer, Barcode Reader, Flash Disk External Printer USB Host Internal Printer Built-in Thermal Printer Reagents D35 Diluent 20 L + L35 Lyse 500 mL Dimensions (H×W×D) 395 × 305 × 380 mm Weight 20 kg* Working Temperature 18–32°C Relative Humidity Maximum 80% at 32°C Storage Temperature -10–50°C Power Supply AC 100–240 V, 50/60 Hz Power Consumption 180 VA
